"The Basic"

23' x 10' (230 sq. ft.) - suggested for business volume of 100 to 250 cups per day, (with limited iced & frozen beverage demand).

"The Classic"

29' x 11' (319 sq. ft.) - suggested for business volume of 200 to 500 cups per day.

"The Palatial"

36" x 11' with bump-out to 21' in center ( 519.2 sq ft.) suggested for business volume of 200 to 700 cups per day, with strong iced & frozen drink demand.
  • 2 - drive up service windows
  • 1 - walk up service window
  • 1 - 2 group espresso machine
  • 2 - espresso burr grinders
  • 1 - single airpot coffee brewer w/ twin hopper portion control grinder, combo unit
  • 1 - granita machine, 2 barrel
  • 1 - ice cube maker, 69 lb. capacity
  • 1 - cash register
  • 1 - coffee condiment/beverage staging area
  • 2 - cup dispensers, box unit, 3 size
  • 1 - 3 compartment dish sink, with drain boards, pre-wash sprayer, & grease interceptor
  • 1 - hand washing sink
  • 1 - mop sink
  • 1 - water purification/manipulation system
  • 1 - water heater
  • 31 cubic feet of refrigerated storagee
  • 86+ sq. ft. of dry goods ingredients & paper product storage
  • 1 - floor safe
  • 1 - employee lockers, 6 compartment unit
  • 1 - coat hooks
  • 1 - ADA restroom
  • no custom cabinetry required
  • 2 - drive up service windows
  • 1 - walk up service window
  • 1 - 3 group espresso machine
  • 2 - espresso burr grinders
  • 1 - single airpot coffee brewer
  • 1 - dual hopper portion control grinder
  • 1 - granita machine, 2 barrel
  • 2 - beverage blenders, commercial
  • 1 - ice cube maker, 450 lb. capacity
  • 2 - cash registers
  • 1 - coffee condiment/beverage staging area
  • 1 - cup dispenser, box unit, 3 size
  • 6 - cup dispensers, under counter, face mounted
  • 1 - 3 compartment dish sink, with drain boards, pre-wash sprayer, & grease interceptor
  • 1 - hand washing sink
  • 1 - mop sink
  • 1 - water purification/manipulation system
  • 1 - water heater
  • 49.4 cubic feet of refrigerated storage
    • or
    42.9 c.f. refrigerated storage, & 6.5 c.f. freezer storage
  • 100+ sq. ft. of dry goods & paper product storage
  • desk/work station, (pull out)
  • floor safe
  • 1 - employee lockers, 6 compartment unit
  • 1 - coat hooks
  • 1 - ADA restroom
  • 2 - drive up service windows
  • 2 - walk up service windows
  • 1 - 3 group espresso machine
  • 2 - espresso burr grinders
  • 1 - double airpot coffee brewer
  • 1 - dual hopper portion control grinder
  • 2 - granita machines, 2 barrel
  • 2 - beverage blenders, commercial
  • 1 - ice cube maker, 450 lb. capacity
  • 1 - soft serve freezer/dispensing unit, 2 flavor w/ swirl
  • 2 - cash registers
  • 2 - coffee condiment/beverage staging areas
  • 1 - cup dispenser, box unit, 3 size
  • 15 - cup dispensers, under counter, face mounted
  • 1 - 3 compartment dish sink, with drain boards, pre-wash sprayer, & grease interceptor
  • 1 - blender dump/rinse sink
  • 1 - drip pan w/ drain grate (for draining washed blender pitchers)
  • 2 - hand washing sinks
  • 1 - mop sink
  • 1 - water purification/manipulation system
  • 1 - water heater
  • 73 cubic feet of refrigerated storage
    • or
    47 c.f. refrigerated storage, & 23 c.f. freezer storage
    or
    73 c.f. refrigerated storage, & 23 c.f. freezer storage
  • (refrigeration replacing soft serve machine)
  • 182+ sq. ft. of dry goods & paper product storage
  • desk/work station, (pull out)
  • floor safe
  • 1 - employee lockers, 6 compartment unit
  • 1 - coat hooks
  • 1 - ADA restroom
